Windows 10 Upgrade BSOD (SYSTEM_SCAN_AT_RAISED_IRQL_CAUGHT_IMPROPER_DRIVER_UNLOAD)
After the Windows 10 setup files have downloaded and its rebooted into the upgrade process we seem to be getting this weird problem.
After the files have copied across (so the first part of the upgrade process) when its doing the installation/configuration i get a BSOD with the following error :
SYSTEM_SCAN_AT_RAISED_IRQL_CAUGHT_IMPROPER_DRIVER_UNLOAD and i cannot seem to figure out what the cause is.
Machine Specs:
- OS: Windows 8.1 Pro
- CPU: Intel Core i7 4790K Haswell Refresh Processor 4.0 GHz
- RAM: 16GB PC3-10666 1333MHz DDR3 Memory (2 x 8GB sticks)
- GPU: NVIDIA GeForce GT740
- MOBO: Asus B85M-G Basic Micro ATX Motherboard
- Hard Drive Setup: All our machines have 1 SSD boot drive and 2x1TB Mechanical drives in a raid 1 setup
We have 2 other machines built pretty much the same and both of them have upgraded no problem, any ideas?
71 Answer
Your crash SYSTEM_SCAN_AT_RAISED_IRQL_CAUGHT_IMPROPER_DRIVER_UNLOAD (d4)is caused by the driver spac.sys which was unexpected unloaded.
*******************************************************************************
* *
* Bugcheck Analysis *
* *
*******************************************************************************
SYSTEM_SCAN_AT_RAISED_IRQL_CAUGHT_IMPROPER_DRIVER_UNLOAD (d4)
A driver unloaded without cancelling lookaside lists, DPCs, worker threads, etc.
The broken driver's name is displayed on the screen.
When possible, the guilty driver's name (Unicode string) is printed on
the bugcheck screen and saved in KiBugCheckDriver.
An attempt was made to access the driver at raised IRQL after it unloaded.
If kernel debugger is available get stack backtrace.
Arguments:
Arg1: fffff801158f3e40, memory referenced
Arg2: 0000000000000002, IRQL
Arg3: 0000000000000001, value 0 = read operation, 1 = write operation
Arg4: fffff8001bed49ec, address which referenced memory
Debugging Details:
------------------
DUMP_CLASS: 1
DUMP_QUALIFIER: 400
BUILD_VERSION_STRING: 10586.63.amd64fre.th2_release.160104-1513
DUMP_TYPE: 2
BUGCHECK_P1: fffff801158f3e40
BUGCHECK_P2: 2
BUGCHECK_P3: 1
BUGCHECK_P4: fffff8001bed49ec
FAULTING_IP:
spac+103e40
fffff801`158f3e40 ?? ???
CPU_COUNT: 8
CPU_MHZ: f9e
CPU_VENDOR: GenuineIntel
CPU_FAMILY: 6
CPU_MODEL: 3c
CPU_STEPPING: 3
DEFAULT_BUCKET_ID: WIN8_DRIVER_FAULT
BUGCHECK_STR: 0xD4
PROCESS_NAME: System
CURRENT_IRQL: 2
ANALYSIS_VERSION: 10.0.10586.567 amd64fre
STACK_TEXT:
00 nt!KeBugCheckEx
01 nt!KiBugCheckDispatch
02 nt!KiPageFault
03 nt!KiProcessThreadWaitList
04 nt!KiRetireDpcList
05 nt!KiIdleLoop
FOLLOWUP_IP:
spac+103e40
fffff801`158f3e40 ?? ???
SYMBOL_NAME: spac+103e40
MODULE_NAME: spac
IMAGE_NAME: spac.sys
DEBUG_FLR_IMAGE_TIMESTAMP: 0
BUCKET_ID_FUNC_OFFSET: 103e40
FAILURE_BUCKET_ID: 0xD4_UNLOADED_MODULE_spac!Unknown_Function
BUCKET_ID: 0xD4_UNLOADED_MODULE_spac!Unknown_Function
PRIMARY_PROBLEM_CLASS: 0xD4_UNLOADED_MODULE_spac!Unknown_FunctionThis driver seams to be part of the Barracuda NextGen Firewall F-Series. So uninstall this tool and do the upgrade.
