What port is this, labeled with "I/F"? [closed]

Any ideas?

3

3 Answers

Well, its seems to be a standard 8 pin mini din port, apparently - if its a sun or apple device, it might be a serial port - it looks identical to the passthrough port on my sun model 5c keyboard .

If it had 7 pins, i'd guess it was a firewire port, since that looks like an old macbook, but the shape is wrong.

6

Been searching around, and from I've gathered, it appears to be some sort of ethernet port. Though it is nowhere mentioned explicitly

Sources: gigabit ethernet port, P113S LF A 10/100 Base-TX / 100 Base-FX Converter and some PDF

But then in another source, it is a general term for input devices (Link PDF)

1

A lot of video cards have a port like this that is for attaching a Composite/Component breakout box dongle. This is a picture of one of the connector, but I have one at home on a 9800 GTX+ that has a different pin layout. This image is from 2004, so the pin layout has probably changed since then.

1
