I am new into Ubuntu 18.04 and I am trying to make my VPS hosted on dedicated server (VMware) working, I tried the automatic network setup during install, but I got an subnet error, because IP and netmask are not in the same subnet.

Then I read a ton of tutorials how to set static IP in netplan, but I am still not able to make it work; now my broadcast IP and netmask are different then the VPS one should be.

My current ifconfig looks like this:

As I said, I tried several tutorials and it was a long pain, because in the VM without network hosted on dedicated server, you can't just copy&paste - you need to write everything by hand, now I tried something about 5 configs and I am lost and tired of typing bad configs. Can you help me out please?

Actual config (50-cloud-init.yaml) looks like this:

Thank you so much for all your help and ideas :)

Further information

Thank you for helping me out, unfortunately, I am sure I have my config from ISP right, it's an bridge for OVH failover IP and as you can read here, their configuration seems to need these settings.

It's all described here and I think that I got it right, even Debian 8 has problems with installation because of the gateway out of subnet, but when you will put it directly in the config after installation, it will work. Here is the doc:

So what I get from it:

1) My main server IP is 144.217.79.168, so according to the documentation, I should replace the last number with 254, so the gateway IP will be 144.217.79.254

For example, if your server’s main IP address is: 123.456.789.012. Your gateway address would therefore be: 123.456.789.254 (from OVH documentation linked above)

2) The failover IP I got is 192.99.91.249, so this will be the IP of my VM (I also generated the MAC address in the OVH admin panel and I inserted this MAC address into the VMware settings, so the network card has the right MAC. You can check that the MAC address on the screen here match the IP in ifconfig posted in my previous post)

3) Here you can see config (/etc/network/interfaces) from my different VM on a diferent server running Debian 8. The base IP of the server is 94.23.208.11

auto eth0
iface eth0 inet static address 193.70.26.224 netmask 255.255.255.255 broadcast 193.70.26.224 post-up route add 94.23.208.254 dev eth0 post-up route add default gw 94.23.208.254 post-down route del 94.23.208.254 dev eth0 post-down route del default gw 94.23.208.254
auto eth1
iface eth1 inet dhcp

and here is the ifconfig output:

root@lfcz:~# ifconfig
eth0 Link encap:Ethernet HWadr 00:50:56:05:94:73 inet adr:193.70.26.224 Všesměr:193.70.26.224 Maska:255.255.255.255 inet6-adr: fe80::250:56ff:fe05:9473/64 Rozsah:Linka AKTIVOVÁNO VŠESMĚROVÉ_VYSÍLÁNÍ BĚŽÍ MULTICAST MTU:1500 Metrika:1 RX packets:49421930 errors:0 dropped:10407 overruns:0 frame:0 TX packets:37347078 errors:0 dropped:0 overruns:0 carrier:0 kolizí:0 délka odchozí fronty:1000 RX bytes:33409153963 (31.1 GiB) TX bytes:15110079692 (14.0 GiB)

Maybe I am just not getting something, but I really don't know, what I should do with the Ubuntu configuration now. Please don't take this post as an offence or arguing against you, I am just trying to post every important information to make helping me easier as I am lost now. Thank you again for all the help!

4

1 Answer

OK, Everything is finished!

OVH just posted a tutorial how to do this, literally posted 9 hours ago, so it was not available when I created this post, you can find the official tutorial including configuration here.

Configuring Network Settings in an Ubuntu 18.04 VM

As of Ubuntu 17.x, Canonical has implemented the use of Netplan for easy-to-use network configuration.

To configure the network interface, open the 01-netcfg.yaml file using the following command:

sudo vim /etc/netplan/01-netcfg.yaml

Edit the file to make it appear as follows:

# This file describes the network interfaces available on your system
# For more information, see netplan(5).
network: version: 2 renderer: networkd ethernets: ens160: dhcp4: no dhcp6: no addresses: [x.x.x.x/32] gateway4: y.y.y.254 nameservers: addresses: [208.67.222.222,208.67.220.220] routes: - to: y.y.y.254/32 via: 0.0.0.0 scope: link

In this file, replace the following pieces of information as instructed:

1. If you replace the VMXNET3 NIC with another one, your NIC may use a different naming convention. If it does, replace "ens160" in the file with the name of your interface. If you don't know the name of your interface, you can find it using the following command:

   ip addr list

2. Next to "addresses", replace "x.x.x.x/32" with the Failover IP to which you have added the vMAC in the OVH US Manager plus the subnet you wish to use in CIDR notation.

3. Next to "gateway4", replace the "y.y.y." with the first three octets of your Dedicated Server's IP address with a final octet of "254". For instance, if your Dedicated Server IP was 1.2.3.4, you would use 1.2.3.254 as your gateway.
4. The DNS name server addresses listed are from OpenDNS. Feel free to use other name servers here, if you choose.
5. In the "routes" section, the y's correspond with your gateway IP address. Fill in these octets accordingly.

Now apply the Netplan settings with the following command:

sudo netplan apply

To test that the VM is fully connected to the Internet, ping example.com. If you get a response, you are good to go. If you do not, restart your VM and attempt the ping again.

Thanks for all the help anyway!
