Ubuntu 18.04.1 - TP-LINK UE330 Ver: 2.0 driver problem

I just buy a new USB 3.0 Gigabit Ethernet Adapter and I can't install it in Ubuntu 18.04.1 server x64 edition.

I contact tp-link support and they send me the driver. I install the driver but my adapter is still without Internet connection. I follow this steps too and without any success.

Anyone can help me to fix this issue?

EDIT:

Output of `ifconfig`
enp19s0: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500 ether 78:2b:cb:e9:d5:3c txqueuelen 1000 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
enx503eaa8b183c: flags=4098<BROADCAST,MULTICAST> mtu 1500 ether 50:3e:aa:8b:18:3c txqueuelen 1000 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536 inet 127.0.0.1 netmask 255.0.0.0 inet6 ::1 prefixlen 128 scopeid 0x10<host> loop txqueuelen 1000 (Local Loopback) RX packets 226 bytes 15022 (15.0 KB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 226 bytes 15022 (15.0 KB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
wlp18s0: flags=4098<BROADCAST,MULTICAST> mtu 1500 ether 18:f4:6a:3f:af:11 txqueuelen 1000 (Ethernet) RX packets 0 bytes 0 (0.0 B) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 0 bytes 0 (0.0 B) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0

Output for sudo lshw -c network

 *-network DISABLED description: Wireless interface product: AR9285 Wireless Network Adapter (PCI-Express) vendor: Qualcomm Atheros physical id: 0 bus info: pci@0000:12:00.0 logical name: wlp18s0 version: 01 serial: 18:f4:6a:3f:af:11 width: 64 bits clock: 33MHz capabilities: pm msi pciexpress bus_master cap_list ethernet physical wireless configuration: broadcast=yes driver=ath9k driverversion=4.15.0-38-generic firmware=N/A latency=0 link=no multicast=yes wireless=IEEE 802.11 resources: irq:17 memory:fbc00000-fbc0ffff *-network description: Ethernet interface product: RTL8101/2/6E PCI Express Fast/Gigabit Ethernet controller vendor: Realtek Semiconductor Co., Ltd. physical id: 0 bus info: pci@0000:13:00.0 logical name: enp19s0 version: 02 serial: 78:2b:cb:e9:d5:3c size: 10Mbit/s capacity: 100Mbit/s width: 64 bits clock: 33MHz capabilities: pm msi pciexpress msix vpd bus_master cap_list rom ethernet physical tp mii 10bt 10bt-fd 100bt 100bt-fd autonegotiation configuration: autonegotiation=on broadcast=yes driver=r8169 driverversion=2.3LK-NAPI duplex=half latency=0 link=no multicast=yes port=MII speed=10Mbit/s resources: irq:18 ioport:e000(size=256) memory:d0b10000-d0b10fff memory:d0b00000-d0b0ffff memory:fb200000-fb21ffff *-network DISABLED description: Ethernet interface physical id: 2 logical name: enx503eaa8b183c serial: 50:3e:aa:8b:18:3c size: 100Mbit/s capacity: 1Gbit/s capabilities: ethernet physical tp mii 10bt 10bt-fd 100bt 100bt-fd 1000bt 1000bt-fd autonegotiation configuration: autonegotiation=on broadcast=yes driver=r8152 driverversion=v1.09.9 duplex=full link=no multicast=yes port=MII speed=100Mbit/s

The name of the file that is in the /etc/netplan/01-netcfg.yaml

CONTENT of /etc/netplan/01-netcfg.yaml

 # This file describes the network interfaces available on your system # For more information, see netplan(5). network: version: 2 renderer: networkd ethernets: enp19s0: dhcp4: yes

Thank you in advance.

12

3 Answers

Try this...

In terminal...

cd /etc/netplan # change directory

sudo cp 01-netcfg.yaml 01-netcfg.HOLD # backup the file

sudo pico 01-netcfg.yaml # edit the file

replace what you see there with this...

# This file describes the network interfaces available on your system
# For more information, see netplan(5).
network: version: 2 renderer: networkd ethernets: enp19s0: dhcp4: yes optional: true enx503eaa8b183c: dhcp4: yes optional: true

then...

sudo netplan generate # generate the config files

sudo netplan apply # apply the new configuration

reboot # reboot the system

review the previous lshw and ifconfig commands to check operation.

6

I had a similar issue and got the card working by doing this:

sudo ip l s dev enx503eaa8b183c up

On 18.04.3 here, with a TP-Link TG-3468. I had to do the following:

sudo ip l s dev enp6s0 up

Then I modified /etc/netplan/01-network-manager-all.yaml to look like this:

network: version: 2 renderer: NetworkManager ethernets: enp6s0: match: macaddress: "12:34:56:78:90:12" set-name: enp6s0 dhcp4: true dhcp-identifier: mac critical: true nameservers: addresses: ["<LAN IP address of router>"]

Then

sudo netplan --debug generate
sudo netplan apply
sudo reboot
