How to get a persistent reverse SSH tunnel using autossh?
(just asked this on SO but was adviced to take it here)
I managed to create a reverse SSH tunnel between a Raspberry Pi 2 and a server of mine (server which has a static IP) and it works fine. The user account I'm using on the server is called "ksproxy" (it's not really a "proxy" but whatever).
Now I'm trying to make autossh (from Debian / Raspbian package autossh) to work too but I'm not succeeding. I may be close.
(I've changed the real IP here in this question to 37.xxx.yyy.zzz to not post the server's actual IP)
Here's what works fine: (no autossh)
On the Rpi:
rspi@antlia:~ $ ssh -N -R 20000:localhost:22 On the server (the one with the static IP):
:~$ ssh rspi@localhost -t -p 20000
rspi@localhost's password:
rspi@antlia:~ $So everything works fine: I enter the password and I get a terminal/prompt.
I can even access the Raspberry Pi from my desktop (by first going through the server), doing:
ssh -t "ssh rspi@localhost -p 20000" password:
rspi@localhost's password:
...
rspi@antlia:~It first ask for the server's password, then for the Pi's password and everything is fine.
So far so good.
Now I try the same but this time with autossh:
rspi@antlia:~ $ autossh -M 20000 -N -i /home/rspi/.ssh/id_rsa
:~$ ssh rspi@localhost -p 20000This "works" but it's just stuck there, doing nothing.
I tried to "-vvv" the output of the ssh commands but it just shows that nothing is going on.
If I try another port, it fails:
:~$ ssh rspi@localhost -p 1234
ssh: connect to host localhost port 1234: Connection refusedIf I try the correct port (20000) but this time with the -t param, same thing: it "works" but I don't get no terminal/prompt.
Here's a the -vvv output
:~$ ssh -vvv rspi@localhost -t -p 20000
OpenSSH_6.7p1 Debian-5+deb8u1, OpenSSL 1.0.1k 8 Jan 2015
debug1: Reading configuration data /etc/ssh/ssh_config
debug1: /etc/ssh/ssh_config line 19: Applying options for *
debug2: ssh_connect: needpriv 0
debug1: Connecting to localhost [127.0.0.1] port 20000.
debug1: Connection established.
debug1: key_load_public: No such file or directory
debug1: identity file /home/ksproxy/.ssh/id_rsa type -1
debug1: key_load_public: No such file or directory
debug1: identity file /home/ksproxy/.ssh/id_rsa-cert type -1
debug1: key_load_public: No such file or directory
...
debug1: Enabling compatibility mode for protocol 2.0
debug1: Local version string SSH-2.0-OpenSSH_6.7p1 Debian-5+deb8u1It's not asking for password, it's not showing any terminal/prompt.
What am I not understanding here or doing wrong?
Note that I don't think it's a firewalling issue as the "non autossh" method works fine (but then I don't get the automatic "always up" / reconnect feature). I'd really like to make autossh work (I know I could find a workaround, like some crontab automatically relaunching my manual SSH tunnel but that'd probably be more brittle than making autossh work).
1 Answer
$ autossh -M 20000 -N -i /home/rspi/.ssh/id_rsa
...
$ ssh rspi@localhost -p 20000In this case, you're not using the ssh -R option to set up a reverse tunnel; you're specifying the autossh -M option instead. The autossh -M parameter causes autossh to set up a tunnel on that port which autossh uses for its own purposes (to regularly test that the SSH link is still working). It's not the equivalent of the ssh -R parameter. When you connect to port 20000 in this scenario, you're being connected to autossh's private connection-testing port.
You should continue to specify the reverse tunnel that you want using ssh's -R option. If you want to use autossh's echo port feature, you should run that on a different port:
$ autossh -M 20002 -N -R 20000:localhost:22
