I want to have wired connection but my laptop has an RJ45 port and my wall port is a Cat6 and the only wire I have is a Cat5e.

I don't want to go out buying new cables and converters so I was wondering if all 3 are compatible.

0

2 Answers

Yes. This should work.

Let’s break down what you are describing.

• RJ45 is the modular connector on an Ethernet cable.
• Cat6 and Cat5e are just designations for rated quality/speed of the cable. Cat6 provides “…lower crosstalk, higher signal-to-noise ratio…” when compared to Cat5e other specs below that level.
• Cat6 is backwards compatible with Cat5e.

So when you say:

“…my wall port is a Cat6…”

Cat6 is just the specification rating of the cabling. The wall port being somehow labeled “Cat6” could just mean that the small bits of wiring within the wall port itself adhere to Cat6 specifications.

But the RJ45 connector on that Cat6 wall port is the same for Cat6 and Cat5e and the spec for Cat6 is backwards compatible to Cat5e so it should all work fine.

0

If the plugs fit, it will work. And a few feet of Cat5e on the end of (probably) a far greater length of Cat6 won't affect performance.

What's a 'Cat6 port'? Cat6 is a cable spec., not a connector type.
